LYNX 3.0 LH19 19mm Thermal Monocular

LYNX LH19 3.0 19mm Thermal Monocular

The HIKMICRO LYNX 3.0 LH19 is the versatile all-rounder of the series, perfectly balancing wide field of view with powerful detection capabilities. Built around a high-resolution 384 × 288 thermal detector and a 19 mm F1.0 lens, it delivers a 1.9× base magnification and a wide 13.8° field of view. This combination offers a detection range of 900 metres while maintaining a broad view (24.2m width at 100m), making it exceptionally effective for tracking moving targets in both forest environments and open fields.

Powered by AI-driven Image Pro 3.0 and Zoom Pro algorithms, the LH19 3.0 delivers superior image quality with an industry-leading NETD < 15 mK sensitivity. This allows for the detection of minute temperature differences in complex backgrounds. Unlike the smaller fixed-focus models, the LH19 features a Manual Focus Ring, allowing professionals to fine-tune sharpness for targets as close as 3 metres. The viewing experience is upgraded with a large 0.49-inch 1920×1080 AMOLED display, providing a massive, immersive picture.

Built for portability and endurance, the LH19 features a replaceable 18650 battery that delivers up to 5 hours of continuous runtime. Weighing just 331 grams, it remains compact enough for jacket pockets while offering robust IP67 protection. With the silent HIKMICRO Shutterless Image System (HSIS), the LYNX 3.0 LH19 is the ultimate choice for hunters and explorers who need a powerful, adaptable device for diverse scenarios.

HIKMICRO LYNX LH19 3.0 Specifications

Image Sensor: VOx Uncooled Focal Plane Arrays
Max. Resolution: 384 × 288
Frame Rate: 50 Hz
Pixel Interval: 12 μm
Response Waveband: 8 μm to 14 μm
NETD: Less than 15 mK (@25°C), F#=1.0
Lens (Focal Length): 19 mm, F1.0
Focus Mode: Focus Ring (Manual Focus)
Min. Focusing Distance: 3.0 m
Magnification: 1.9× – 15.2× (8× Digital Zoom)
Field of View (H × V): 13.8° × 8.4° / 24.2 m × 14.7 m @ 100 m
Detection Range: 900 m
Display: 0.49 inch, AMOLED, 1920 × 1080
Contrast Adjustment: Yes
Brightness Adjustment: Yes
Palettes: Black Hot, White Hot, Red Hot, Fusion, Red Monochrome, Green Monochrome
Tone Adjustment: Cold, Warm
Zoom Pro: Yes
HSIS (HIKMICRO Shutterless Image System): Yes
Image Pro 3.0: Yes
Battery Type: Replaceable and rechargeable 18650 battery
Runtime: ~5 hours (@25°C) / 4.5 hours (@-20°C)
Protection Level: IP67
Weight: 331 g (with battery)

LYNX LH19 3.0 19mm

KEY FEATURES

High-Sensitivity Thermal Module

Equipped with a 384×288 sensor and incredible NETD < 15 mK sensitivity, the LH19 captures the finest heat details, ensuring clear target recognition even in rain, fog, or cold environments.

Versatile 19mm Optic & Manual Focus

The 19mm lens provides a 13.8° field of view, offering a wide observation area perfect for tracking moving targets. The Manual Focus Ring allows you to dial in precise sharpness for targets from 3 metres to infinity.

AI-Powered Image Enhancement

Integrated Image Pro 3.0 and Zoom Pro algorithms actively sharpen images and reduce pixilation, ensuring that details remain crisp even when using digital zoom.

HIKMICRO Shutterless Imaging System (HSIS)

The HSIS technology eliminates the mechanical “click” and image freeze of calibration, providing a completely silent and fluid viewing experience—critical for maintaining stealth.

High-Definition OLED Display

Featuring a premium 0.49-inch 1920×1080 AMOLED screen, this model offers a significantly larger and clearer viewing area than entry-level devices, reducing eye strain and improving detail perception.
